Toro Dingo TX 700 Track Loader, Wide
Toro Dingo TX 700 Track Loader, Wide
Toro Dingo TX 700 Track Loader, Wide
Toro Dingo TX 700 Track Loader, Wide

Toro Dingo TX 700 Track Loader, Wide

700 lb Diesel Track Loader, Wide Track
“Nimble meets wide-track turf protection.”

The Toro Dingo TX 700 Wide brings award-winning TX 700 maneuverability and 24.7 HP Yanmar diesel performance to wide-track configuration, providing maximum turf protection on lawns and landscapes. Turf-Friendly MERT tracks and the patented control system make it the ideal wide-track compact loader.

Operating Weight

Operating Weight

2,862 lb

Operating Capacity

Operating Capacity

708 lb

Engine Horsepower

Engine Horsepower

24.7 HP

Ground Speed (Fwd)

Ground Speed (Fwd)

4.3 mph

Tip Capacity

Tip Capacity

2,023 lb

Hinge Pin Height

Hinge Pin Height

73.5 in

Product Capabilities
Wide-Track Maneuverability for Turf-Sensitive Sites

The Toro Dingo TX 700 Wide brings award-winning TX 700 maneuverability and 24.7 HP Yanmar diesel performance to wide-track configuration, providing maximum turf protection on lawns and landscapes. Turf-Friendly MERT tracks and the patented control system make it the ideal wide-track compact loader.

Features of Toro Dingo TX 700 Track Loader, Wide

01

Dual Independent Hydrostatic Drive

Independent hydrostatic motors drive each track separately, enabling smooth zero-radius turns, feathered speed control on slopes, and precise positioning through the tightest jobsite conditions — all from the walk-behind operator platform.

02

Universal Skid Steer Attachment Interface

The standard skid steer quick-attach system accepts hundreds of Toro and compatible aftermarket attachments — augers, trenchers, buckets, grapples, pallet forks, stump grinders, and more — turning the Dingo into a true multi-function machine for any application.

03

MERT Track with Turf-Friendly Tread

MERT (Maximum Extra Rubber Track) technology provides a larger rubber contact area for reduced ground pressure and excellent flotation on soft, wet, and turf surfaces. Turf-style tread patterns on wide-track models minimize surface disruption on finished lawns and commercial landscapes.

04

Compact Access Through 36-Inch Gates

With narrow-track models as slim as 34 inches wide, the Dingo TX passes through standard 36-inch residential gate openings, between fences, along building foundations, and inside structures inaccessible to conventional compact track loaders and skid steers.

05

Toro Patented Control System

Toro's patented proportional control system puts precise drive and loader functions at the operator's fingertips from the walk-behind platform, enabling accurate, smooth operation with minimal training — whether feathering into attachment work or navigating complex site obstacles.

06

4-Pump Independent Hydraulic System

Four independent hydraulic pumps deliver simultaneous optimized flow to both traction circuits, the loader arm, and the auxiliary circuit — ensuring full loader arm response and attachment performance are always available without sacrificing drive capability under heavy loads.

Complete Machine Data.

Performance
Operating Weight 2,862 lb (1,298 kg)
Rated Operating Capacity 708 lb (321.1 kg)
Tip Capacity 2,023 lb (918 kg)
Loader Arms Radial
Ground Pressure 6.4 PSI
Ground Speed – Forward Up to 4.3 mph (7.0 km/h)
Ground Speed – Reverse Up to 4.0 mph (6.4 km/h)
Traction Dual Hydrostatic Pump
Engine & Hydraulics
Engine Make Yanmar
Engine Model 3TNV80F
Engine Horsepower 24.7 HP (18 kW) @ 3,000 rpm
Engine Displacement 1,262 cc (77 cu.in.)
Fuel Type Diesel
Fuel Tank Capacity 5.5 gal (20.8 L)
Oil Capacity 3.6 qt (3.4 L)
Air Filter Dual Element
Cooling System Combo Downflow Radiator and Oil Cooler
Hydraulic Flow – Auxiliary 13.7 GPM
Hydraulic Flow – Traction 14.5 GPM
Dimensions
Track Type MERT Track with Turf Friendly Tread
Track Width 9.1 in (23.1 cm)
Track Length 126.6 in (321.5 cm)
Wheelbase 39 in (99.0 cm)
Ground Clearance 5.25 in (13.3 cm)
Length (Without Bucket) 82 in (208.3 cm)
Length (With Bucket) 102.8 in (261.3 cm)
Width (Without Bucket) 40.2 in (102.1 cm)
Width (With Bucket) 41.4 in (105.2 cm)
Height 55.3 in (140.5 cm)
Hinge Pin Height 73.5 in (186.7 cm)
Max Operating Height 97 in (246.3 cm)
Reach – Fully Raised 31 in (78.7 cm)
