1,300 lb INTELESCOPE® Telescoping Track Loader
“More reach. More capacity. All Dingo.”

The Toro Dingo TX 1300 delivers 1,300 lb rated operating capacity and an exclusive INTELESCOPE® loader arm extending 26 extra inches for 9-foot-plus hinge pin height. A 37 HP Yanmar Tier 4 diesel engine powers the most capable Dingo TX track loader for landscape, hardscape, and tree care work.

Operating Weight

Operating Weight

3,858 lb

ROC (Retracted)

ROC (Retracted)

1,300 lb

Engine Horsepower

Engine Horsepower

37 HP

Max Ground Speed

Max Ground Speed

4.7 mph

Tip Capacity

Tip Capacity

3,714 lb

Hinge Pin Height

Hinge Pin Height

109.2 in

Product Capabilities
Exclusive INTELESCOPE® Technology

The Toro Dingo TX 1300 delivers 1,300 lb rated operating capacity and an exclusive INTELESCOPE® loader arm extending 26 extra inches for 9-foot-plus hinge pin height. A 37 HP Yanmar Tier 4 diesel engine powers the most capable Dingo TX track loader for landscape, hardscape, and tree care work.

Features of Toro Dingo TX 1300 Track Loader

01

Dual Independent Hydrostatic Drive

Independent hydrostatic motors drive each track separately, enabling smooth zero-radius turns, feathered speed control on slopes, and precise positioning through the tightest jobsite conditions — all from the walk-behind operator platform.

02

Universal Skid Steer Attachment Interface

The standard skid steer quick-attach system accepts hundreds of Toro and compatible aftermarket attachments — augers, trenchers, buckets, grapples, pallet forks, stump grinders, and more — turning the Dingo into a true multi-function machine for any application.

03

MERT Track with Turf-Friendly Tread

MERT (Maximum Extra Rubber Track) technology provides a larger rubber contact area for reduced ground pressure and excellent flotation on soft, wet, and turf surfaces. Turf-style tread patterns on wide-track models minimize surface disruption on finished lawns and commercial landscapes.

04

Compact Access Through 36-Inch Gates

With narrow-track models as slim as 34 inches wide, the Dingo TX passes through standard 36-inch residential gate openings, between fences, along building foundations, and inside structures inaccessible to conventional compact track loaders and skid steers.

05

Toro Patented Control System

Toro's patented proportional control system puts precise drive and loader functions at the operator's fingertips from the walk-behind platform, enabling accurate, smooth operation with minimal training — whether feathering into attachment work or navigating complex site obstacles.

06

4-Pump Independent Hydraulic System

Four independent hydraulic pumps deliver simultaneous optimized flow to both traction circuits, the loader arm, and the auxiliary circuit — ensuring full loader arm response and attachment performance are always available without sacrificing drive capability under heavy loads.

Complete Machine Data.

Performance
Operating Weight 3,858 lb (1,750 kg)
ROC – Retracted 1,300 lb (589.6 kg)
ROC – Extended 618 lb (280.3 kg)
Tip Capacity 3,714 lb (1,685 kg)
Ground Pressure 5.5 PSI
Ground Speed – Fwd/Rev Up to 4.7 mph (7.6 km/h)
Loader Arms Radial
Traction Dual Hydrostatic Pump
Engine & Hydraulics
Engine Make Yanmar
Engine Model 3TNV88C
Engine Horsepower 37 HP (27 kW)
Fuel Type Diesel
Fuel Tank Capacity 11 gal (41.6 L)
Oil Capacity 5 qt (4.7 L)
Air Filter Remote Dual Element
Cooling System Combo Downflow Radiator and Oil Cooler
Hydraulic Flow – Auxiliary 14.3 GPM
Hydraulic Flow – Traction 13.4 GPM
Hydraulic Pressure 3,200 PSI
Dimensions
Track Type MERT track with "TF" style tread
Track Width 9.1 in (23.1 cm)
Track Length 126.6 in (321.5 cm)
Wheelbase 39 in (99.0 cm)
Ground Clearance 5.9 in (14.9 cm)
Length (Without Bucket) 84.9 in (215.6 cm)
Length (With Bucket) 103.1 in (261.8 cm)
Width (Without/With Bucket) 46 in (116.8 cm)
Height 56.5 in (143.5 cm)
Hinge Pin Height – Retracted 89.4 in (227.0 cm)
Hinge Pin Height – Extended 109.2 in (277.3 cm)
Max Operating Height 133 in (337.8 cm)
Dump Height – Retracted 70.9 in (180.0 cm)
