XCMG Articulated Hauler Truck
XDA45U
The XCMG XDA45U Articulated Dump Truck is engineered to excel on the toughest terrains, combining power and efficiency for maximum productivity. With its robust engine and impressive payload capacity, it ensures your operations run smoothly and reliably, delivering consistent performance even in demanding conditions.
Financing options at 0% interest available.
Experience the XDA45U in action on your job site!
Payload
90,390 lb
Rated Power
523 hp
Fuel Tank Capacity
185 gal
Engine Type
Cummins QSK19 T4F
Cargo Capacity
32 yd³
Max Travel Speed
34.2 mph
- 3 Years Standard Warranty
- 24/7 Parts & Technical Support
- Delivery Available
The XCMG XDA45U Articulated Dump Truck is engineered to excel on the toughest terrains, combining power and efficiency for maximum productivity. With its robust engine and impressive payload capacity, it ensures your operations run smoothly and reliably, delivering consistent performance even in demanding conditions.
Financing options at 0% interest available.
Experience the XDA45U in action on your job site!
Features of XDA45U
01
High-Output Cummins Engine
Powerful T4F diesel delivers the torque needed to move maximum payload up grades and across soft ground.
02
6x6 All-Wheel Drive
Permanent 6-wheel drive with automatic lockups conquers soft, muddy, and steep haul routes where rigid trucks bog down.
03
Load-Sensing Hydraulic Bed
Fast-cycle tipping hydraulics with automatic bed-down interlocks keep haul cycles short and jobsites safe.
04
ROPS / FOPS Certified Cab
Wide, air-conditioned operator station with excellent visibility, ergonomic controls, and integrated telematics.
05
Retarder & Auxiliary Braking
Engine-driven retarder and transmission-integrated brakes provide continuous downgrade speed control without overheating the service brakes.
06
Auto-Traction Control
Electronically-controlled inter-axle and cross-axle differential locks engage automatically when wheelslip is detected, maintaining forward motion in mud and soft ground.
Complete Machine Data.
| Payload | 90,390 lb |
| Rated Power | 523 hp |
| Engine Type | Cummins QSK19 T4F |
| Cargo Capacity | 32 yd³ |
| Max Travel Speed | 34.2 mph |
| Heap Capacity (SAE 2:1) | 32 yd³ |
| Struck Capacity | 23 yd³ |
| Body Material | HARDOX 400 Wear-Resistant Steel |
| Dump Time (Full Raise) | 12 sec |
| Lowering Time | 9 sec |
| Body Tipping Angle | 70° |
| Overall Length | 35 ft 7 in |
| Overall Width | 10 ft 6 in |
| Overall Height (Cab) | 12 ft 6 in |
| Loading Height (Empty) | 10 ft 1 in |
| Wheelbase | 15 ft 5 in |
| Ground Clearance | 19.7 in |
