750 lb Electric Track Loader, Narrow Track
“Electric performance. No limits.”

The Toro eDingo TX 750 Narrow delivers 750 lb rated operating capacity with zero-emission electric drive and narrow MERT tracks for tight-access sites. A 22.3 kWh HyperCell Lithium Ion battery powers a full workday of clean, quiet operation for landscaping, maintenance, and construction work.

Operating Weight

Operating Weight

2,561 lb

Operating Capacity

Operating Capacity

750 lb

Battery Capacity

Battery Capacity

22.3 kWh

Ground Speed (Fwd)

Ground Speed (Fwd)

4.0 mph

Tip Capacity

Tip Capacity

2,142 lb

Hinge Pin Height

Hinge Pin Height

81 in

Product Capabilities
Zero-Emission Track Loader for Sensitive Sites

The Toro eDingo TX 750 Narrow delivers 750 lb rated operating capacity with zero-emission electric drive and narrow MERT tracks for tight-access sites. A 22.3 kWh HyperCell Lithium Ion battery powers a full workday of clean, quiet operation for landscaping, maintenance, and construction work.

Features of Toro eDingo TX 750 Electric Track Loader, Narrow

01

Zero-Emission HyperCell Electric Drive

Toro's electric drive system produces zero exhaust emissions, making the eDingo fully compliant for indoor use in greenhouses, barns, arenas, enclosed buildings, and any environment where combustion engine exhaust is prohibited, unsafe, or undesirable.

02

HyperCell Lithium Ion Battery Technology

Toro's proprietary HyperCell Lithium Ion battery delivers consistent power output from full charge to near-empty — unlike lead-acid batteries that fade as they discharge — while providing long pack life with minimal degradation over thousands of charge cycles.

03

Universal Skid Steer Attachment Compatibility

The standard skid steer quick-attach interface accepts the full Toro Dingo attachment library and hundreds of compatible aftermarket tools, making the eDingo as versatile as any gas-powered Dingo with the added benefit of clean, quiet electric power.

04

Near-Silent Operation for Sensitive Sites

Near-silent electric operation meets the noise requirements of residential neighborhoods, hospital grounds, school properties, indoor venues, and early-morning commercial starts where traditional engine-powered equipment would disturb occupants or violate local ordinances.

05

Simple Overnight Charging

Standard 120V or 240V outlet charging eliminates diesel fuel infrastructure, fuel delivery logistics, or specialized charging equipment. Simply plug in at the end of the workday for a full charge ready for the next morning shift.

06

Radial Lift Path for Consistent Force

The radial lift arm design delivers consistent breakout force and lift performance throughout the arc, making the eDingo equally capable for bucket loading, grading, and heavy attachment work as any comparable diesel-powered compact utility loader.

Complete Machine Data.

Performance
Operating Weight 2,561 lb (1,161.6 kg)
Rated Operating Capacity 750 lb (340 kg)
Tip Capacity 2,142 lb (971.5 kg)
Loader Arms Radial
Ground Speed – Forward Up to 4.0 mph (6.4 km/h)
Ground Speed – Reverse Up to 2.0 mph (3.2 km/h)
Traction Electrically Driven
Battery & Hydraulics
Fuel Type Electric
Battery Type / Chemistry Toro HyperCell Lithium Ion
Battery Capacity 22.3 kWh
Charging Requirements 240V
Dimensions
Track Type MERT track with "B" style tread
Track Width 5.4 in (13.7 cm)
Track Length 126.6 in (321.5 cm)
Ground Clearance 5.8 in (14.7 cm)
Length (Without Bucket) 66 in (167.6 cm)
Width 31.5 in (80.65 cm)
Height 54.5 in (138.4 cm)
Hinge Pin Height 81 in (205.7 cm)
Max Operating Height 106.6 in (270.7 cm)
Reach – Fully Raised 21.2 in (53.6 cm)
Dump Angle 40°
